JRC JMA-7710-6 - Setting Range Unit in KM

3 – 37
3.3
3.3.19 Setting Range Unit in KM
This function is used to switch the range from the own ship to the cursor or the VRM 1/2 range unit to km or
nm.
The cursor is selected by VRM1.
Procedures
Procedures
1. Press the
SUB
MENU
key to open the SUB MENU.
2. Press the
2
key to open the RADAR #2 menu.
3. Press the
7
key to select "KM ／ NM VRM1".
In case of VRM2, press the
8
key to select "KM ／ NM VRM2".
4. Press the
7
key to select "KM" or "NM" on VRM1.
In case of VRM2, press the
8
key to select "KM" or "NM" on VRM2.
5. Press the
ENT
key to confirm the setting.
Exit
Exit
6. Press the
SUB
MENU
key
Radar #2
1. GYRO 0.0°
2. EBL BEARING
TRUE RELATIVE
3. PARALLEL INDEX LINE
OFF ON
4.
5. CURSOR MENU
6. STERN FLASH
OFF ON
7. KM ／ NM VRM1 KM
NM
8. KM ／ NM VRM2 KM
NM
RADAR #2 0. PREV
