3.3
3.3.23.6 Setting Vector Display
This function is used to set the plot display mode (true/relative).
The default setting is the true vector mode.
In the true vector mode, the own ship vector is displayed with a thick line.
The vector mode information is always displayed on the scree.
Procedures
Procedures
1. Press the
MAIN
MENU
key to open the MAIN MANU.
2. Press the
8
key to select "VECTOR".
3. Press the
8
key to select "TRUE" or "RELATIVE".
4. Press the
ENT
key to confirm the setting. The vector display changes
to the true or relative mode.
5. Press the
MAIN
MENU
key.
or
Procedures
Procedures
Press the
VECT
TRK
key to select "TRUE" or "RELATIVE".
The vector display changes to the true or relative mode.
Main menu
1. RADAR ／ TRACK BRILL ● [DAY1]
2. RR ／ VRM ／ EBL BRILL ● [DAY1]
3. ATA BRILL ● [DAY1]
4. GRAPHIC DATA BRILL ● [DAY1]
5. PROCESS OFF PROC1 PROC2 PROC3
6. IR OFF
IR1 IR2 IR3
7. FLOATING EBL
OFF ON
8. VECTOR
TRUE RELATIVE
9. GRAPHIC DATA DISP OFF
Attention
MAIN MANU
