JRC JMA-7710-6 User Manual

1 – 4
1
Spare parts and attachments
Item Code Qty. Remarks
Spare parts 6ZXRD00194 6 Display unit fuse MF60NR-10A
6 Display unit fuse MF60NR-5A
3 Display unit fuse MF60NR-0.5A
6 Display unit fuse MF61-TS7
9 Display unit power supply circuit fuse
MF51NN-3.15A
3 Display unit power supply circuit fuse
MF51NN-10A
12 Display unit NSK circuit fuse MF51NN-0.5A
3 Display unit monitor power supply circuit fuse
MF51NN-0.5A
2 Scanner unit NKE-1055 carbon brush S00152-5C-70
2 Scanner unit NKE-1056 carbon brush 54511-03
Hood MPOL30274A 1
Instruction manual 7ZPRD0524 1
Equipment componets
1.3 Composition
Remarks
Radar type Scanner unit Display unit
JMA-7710-6 10 kW
JMA-7725-6 25 kW
JMA-7725-9 25 kW
Trans-
mitting
output
Band Ship's power supply
NKE-1055-6
(6ft slot anttenna) × 1
NKE-1056-6M
(6ft slot antenna) × 1
NKE-1056-9M
(9ft slot antenna) × 1
NCD-3901-2
× 1
NCD-3901-2
× 1
NDC-3901-2
× 1
X
AC220V,
50 ／ 60Hz, 1φ
AC100 ／ 110V,
50 ／ 60HZ, 1φ
