6.2.2.3 Application-specific data
Magnetising current in % of the rated motor current
Max. torque in % rated torque
Max. current in % rated motor current
Maximum torque at start of field weakening
Field weakening speed in % of the rated field weakening
speed
DC reference voltage in V
The magnetising current can be preset manually in order to reduce motor losses
(=> Chapter 6.2.5 Magnetizing current)
automatic calculation of the magnetising current from cos phi
Manual setting of a magnetising current
In order to protect the mechanism against excessive torques, the torque can be
limited with dr11.
Maximum permissible torque in% of rated torque
If a motor is energized with multiple of the maximum permissible value, it can not
be protected against destruction either by the motor protection function nor by the
temperature sensors. Therefore the maximum current can be limited.
Maximum permissible motor current in% of the rated motor current
The application point of the field weakening operation and the limiting characteristic
of the motor is defined with dr13 and dr25 (=> Chapter 6.2.10 Field weakening).
The default values are generally sufficient for an initial start-up.
Maximum torque at start of field weakening
