Speed for using the field weakening in % of the rated field weakening speed
(rated value calculated from rated motor voltage, DC link voltage and rated frequency)
The DC link voltage is defined with dr28, designed for the limiting characteristic
and the field-weakening range.
The expected DC link voltage, which is dependent on the mains voltage (√2 *
U
mains
) or the AFE voltage should be entered in this object (see Chapter 6.2.10
Field weakening).
DC reference voltage in V
0 = KTY 84-130, 1 = PTC, 2 = via encoder, 3 = KTY
83 110, 4 = PT1000
Rated current for software motor protection function
in % rated motor current
Cooling type (self or separately cooled)
The overtemperature motor protection is parameterized with this objects (=> Chap-
ter 4.4.5 Overtemperature motor (dOH) and chapter 4.4.6 Motor protection switch
OH2 ).
