10.2.1.1.4 Inserted fieldbus node address
Telegrams incoming at the device via the fieldbus interface are transmitted to the object
directory of the inverter by default and after each reset of the device.
If it is requested to address another object directory with DIN66019 telegrams sent via the
fieldbus interface, the corresponding node address can be set via parameter fb16
fieldbus node injection .
The DIN66019 telegrams of the fieldbus interface are transmitted to the object directory,
which is addressed via the node address in fb16 .
Node address of the object directory where the DIN66019 tele-
grams are sent which are sent to the fieldbus interface.
Default value = value in fb13
➢ Fb16 is a volatile parameter and is set to the value of fb13 at every reset.
Thus, the object directory of the inverter is automatically addressed after
every reset.
10.2.1.2 DIN66019 baud rate
The communication speed can be adjusted via the baud rate. The following baud rates
are available depending on the control type.
The baud rate is 38400 bit/s after a power-on reset or after switching on
of the device and must be switched from the DIN66019 master to another
value, if required. The baud rate is reset to 38400 bit/s after approx. 10s if
the interface is not used.
10.2.1.3 Operator config data
An operator connected to the device via the diagnostic interface requires (for optimal op-
eration) information about the characteristics of the diagnostic interface and the object
directory.
These are provided via the structure de10 "Operator config data“.
