Diagnostic interface
504
© 2022 KEB Automation KG
de10
operator cfg data
0x200A
Subidx
Meaning
Note
1
idx start object
long
RW
Contains index and subindex of the object that the
operator shall display after the start. The possibility
to specify a subindex is not supported by all ver-
sions of the operator software.
2
supported baud rates
long
RO
List of supported baud rates
3
baud rate addr
word
RO
Address of the object to change the baud rate.
4
software version addr
long
RO
Address of the object of the software version.
5
software date addr
long
RO
Address of the object of the software date.
6
supported services 31-0
long
RO
List of supported DIN66019 services (31-0)
7
supported services 63-32
long
RO
List of supported DIN66019 services (63-32)
8
watchdog addr
long
RO
Address of the object of the watchdog function.
9
com mode
long
RW
Communication modes (see 0)
10
Node Id object
long
RO
Address of the object of the inverter Node ID
11
MAC address object
long
RO
Address of the object of the MAC address
12
IP address object
long
RO
Address of the object of the IP address (Ethernet)
13
IP subnet mask object
long
RO
Address of the object of the subnet mask
14
IP gateway address object
long
RO
Address of the object of the gateway address
15
IP scan name object
long
RO
Address of the object for the scan name function
16
EoE IP address obejct
long
RO
Address of the object of the EoE IP address
17
EoE IP subnet mask object
long
RO
Address of the object of the EoE subnet mask
18
EoE IP gateway address
object
long
RO
Address of the object of the EoE gateway address
idx start object
0x200A [1]
Description
Default value:
Format: 0x00SSIIII
(Highestbyte = 0, 3. Byte = Subindex Lowword = Parameter-
Index)
0x00002C01 (ru01)
The support of the subindex is depending
on the version of the operator software
supported baud rates
0x200A [2]
Description
Default value:
Bit 0: Baud rate index 0 (1200 bit/s)
Bit 1: Baud rate index 1 (2400 bit/s)
Bit 2: Baud rate index 2 (4800 bit/s)
Bit 3: Baud rate index 3 (9600 bit/s)
Bit 4: Baud rate index 4 (19200 bit/s)
Bit 5: Baud rate index 5 (38400 bit/s)
Bit 6: Baud rate index 6 (55500 bit/s)
Bit 7: Baud rate index 7 (57600 bit/s)
Bit 8: Baud rate index 8 (100000 bit/s)
Bit 9: Baud rate index 9 (115200 bit/s)
Bit 10: Baud rate index 10 (125000 bit/s)
Bit 11: Baud rate index 11 (250000 bit/s)
Bit 12: Baud rate index 12 (500000 bit/s)
0x00001FE0
(Bit 5, 6, 7, 8, 9, 10, 11 and 12)
baud rate addr
0x200A [3]
Description
Default value:
Format: 0xIIII (index, subindex always 0, only VAR objects)
0x2B0E
software version addr
0x200A [4]
Description
Default value:
Format: 0xSSSSIIII (highword = subindex, lowword = index)
0x00002010
software date addr
0x200A [5]
Description
Default value:
Format: 0xSSSSIIII (highword = subindex, lowword = index)
0x00002011
