KEB COMBIVERT F6 Programming Manual

Safety module objects
526
© 2022 KEB Automation KG
pa: PROFIsafe parameters:
Index
Name
affects on KEB specific object:
Type 3
Type 5
0x3D00
PROFIsafe device frame
elements
1. Status byte of the PROFIsafe
telegram (from SM3)
2. First part of the CRC2 of the
status word
3. Second part of the CRC2 of
the status word
●
0x3D01
PROFIsafe safe inputs
(SafetyModule -> Con-
troller)
1. - 5. Listing of the contents of the
RPOFIsafe telegram from the SM3 to
the safe controller in 16-bit values.
●
0x3D02
PROFIsafe controller
frame elements
1. Control byte of the PROFIs-
afe telegram (to the SM3)
2. First part of the CRC2 of the
control word
3. Second part of the CRC2 of
the control word
●
0x3D03
PROFIsafe safe outputs
(Controller -> SafetyMod-
ule)
1. - 5. Listing of the contents of the
RPOFIsafe telegram from the safe
controller to the SM3 in 16-bit values.
●
0x3D04
PROFIsafe state ma-
chine info
Display of the internal PROFIsafe
state machine and the status of the F
parameters (on the SM3).
●
0x3D05
PROFIsafe alarms
1. – 10. Display of alarms sent by the
SM3 via PROFIsafe.
●
0x3D08
PROFIsafe safety mod-
ule PD init
1. Address of the PROFIsafe
Rx mapping
2. Address of the PROFIsafe Tx
mapping
3. ID of the configured PROFIs-
afe telegram sent by the con-
troller during startup.
●
0x3D09
PROFIsafe F-Parameter
F parameters sent by the controller:
1. PrmFlag1
2. PrmFlag2
3. Source Address
4. Destination Address
5. watchdog time
6. watchdog time 2
7. iPar CRC
8. parameter CRC
●
