15.2
Adjusting the Transmit and Receive Capabilities of the
Transceiver (Panel Tuning Mode)
Panel Tuning Mode can be used to adjust transmit and receive capabilities of the transceiver by using the operation panel
of the transceiver.
Note
Panel Tuning Mode does not function in a Multi RF Deck/ Multi Control Head structure for Mobile.
Operating the transceiver
1
Turn the transceiver ON while pressing and holding the Back ([
]) key.
A Power-on Tone A (1 beep) sounds from the transceiver, and then the
market
code of the transceiver appears for 2 sec. For Portable, the battery
type also appears.
The transceiver enters Panel Test Mode after a lapse of 2 sec.
2
Press the Menu ([
]) key.
The transceiver enters Panel Tuning Mode.
Tuning FuncCh
+
+
25
An SQ5 1- 1
Test PointVolue
+
2.4
RAST 4096
Note
0
Refer
to the service manual for instructions on how to operate the transceiver in Panel Tuning Mode, and on how to adjust
transmit and receive capabilities.
0
To end Panel Tuning Mode, the transceiver must be turned OFF.
Configuration using KPG-D1/ D1N
Configuring whether to permit the use of Panel Tuning Mode (
Transceiver
Settings > Optional Features > Optional
Features 1 > Mode)
15 MODE
15.2 Adjusting the Transmit and Receive Capabilities of the Transceiver (Panel Tuning Mode)
Common FUNC (K, F)/Ver 2.20 241
CONTENTS INDEX
To Next Page
