Embed the 4 tabs of KRK-14HM in KCH-19M.
Figure 17-6 Attaching KRK-14HM
Note
Lock KRK-14HM in place by applying appropriate pressure.
4
Confirm the DIP switch configuration.
When writing the firmware for the initial configuration, confirm that the Dip switch (1 to 4)
equipped
on each interface adapter (KRK-14H, KRK-15B, and KCH-20R) is in the ON position.
17 STRUCTURING A MULTI RF DECK/ MULTI CONTROL HEAD
