Kenwood NX-5200K3 Common Function Reference

Updating the Firmware
Write the firmware version 1.62.00 or later into each of the following devices:
0
NX-5000 RF Deck with KRK-15BM
0
KCH-19M with KRK-14HM
0
KCH-20RM
KCH-20RM
KCH-19M
w
ith KRK-14HM
NX-5000 RF Deck
with KRK-15BM
Figure 17-7 NX-5000 RF Deck with KRK-15BM/ KCH-19M with KRK-14HM/ KCH-20RM
Repeat the procedure below to write the firmware into each of the devices above.
1
Connect the RF Deck to the Control Head by using the KCT-71 cable, and turn the transceiver ON.
KCT-71
Figure 17-8 Connection of the KCT-71 Cables
Note
Connect the KCT-71 cable to the upper connector of KRK-15BM.
17 STRUCTURING A MULTI RF DECK/ MULTI CONTROL HEAD
17.1 Initial Configuration for Multi RF Deck/ Multi Control Head
Common FUNC (K, F)/Ver 2.20 340
CONTENTS INDEX
