Kenwood NX-5200K3 Common Function Reference

2
Remove the Control Head.
Remove the Control Head from a Multi RF Deck system.
Control Head
2
RF Deck 3
KRK-15B
RF Deck 2
KRK-15B
Control Head
1
RF Deck 1
KRK-15B
Control Head
2
Removal
Figure 17-32 Removal of Control Head 2
3
Install the new Control Head.
Install the new Control Head in a Multi RF Deck system.
Control Head
2
RF Deck 3
KRK-15B
RF Deck 2
KRK-15B
Control Head
1
RF Deck 1
KRK-15B
Control Head
2
Figure 17-33 Installation of Control Head 2
17 STRUCTURING A MULTI RF DECK/ MULTI CONTROL HEAD
17.3 Replacing an RF Deck/ Control Head
Common FUNC (K, F)/Ver 2.20 353
