Kenwood NX-5200K3 Common Function Reference

Table 19-8 Available Functions for COM Ports
Range
Communication Ports
COM port 0 COM port 1 COM port 2
None The transceiver can communicate with KPG-D1/ D1N.
Data
The transceiver can remotely be controlled using PC commands.
The transceiver can communicate with KPG-D1/ D1N.
GPS -
Position data can be acquired from the GPS receiver unit.
Also,
the transceiver can send the received GPS data when
the transceiver receives the GPS data from another
transceiver.
The transceiver can communicate with KPG-D1/ D1N.
Data + GPS Data Output
The transceiver can remotely be controlled using PC commands.
The
transceiver will send GPS data by adding STX and ETX when the transceiver receives
GPS data from another transceiver.
The transceiver can communicate with KPG-D1/ D1N.
Transparent -
The port functions as the data communication port for the
Transparent data communication using NXDN protocol.
Transparent 2 (NXDN) -
The port functions as the data communication port for the
Transparent data communication using NXDN protocol
which the communication method is optimized. By using
Transparent
2 (NXDN), data can be sent more efficiently than
using Transparent.
COM port Bluetooth
Various functions can be assigned to Bluetooth communication ports.
Table 19-9 Available Functions for Bluetooth Communication Ports
Range Bluetooth Communication Port
None The transceiver can communicate with KPG-D1/ D1N.
Data
The transceiver can remotely be controlled using PC commands.
The transceiver can communicate with KPG-D1/ D1N.
Data + GPS Data
Output
The transceiver can remotely be controlled using PC commands.
The
transceiver will send GPS data by adding STX and ETX when the transceiver receives GPS
data from another transceiver.
The transceiver can communicate with KPG-D1/ D1N.
Transparent
The port functions as the data communication port for the Transparent data communication using
NXDN protocol.
Transparent 2 (NXDN)
The port functions as the data communication port for the Transparent data communication using
NXDN protocol which the communication method is optimized.
By using Transparent 2 (NXDN), data can be sent more efficiently than using Transparent.
Note
0
For Mobile, the PC command such as J Command which notifies a user that the transceiver status has been changed
cannot be sent from the COM port 0.
0
If “Display Unit” is configured in Bluetooth Interface Selection, “Transparent” and “Transparent 2 (NXDN)” cannot be
configured in COM port Bluetooth.
0
Refer to “Communication Ports” in “Multi RF Deck/ Multi Control Head” for the configuration of COM port in a Multi RF
Deck/ Multi Control Head structure for Mobile.
0
To use COM port Bluetooth, a connection by Serial Port Profile of Bluetooth is required. Refer to “About Serial Port
Profile (SPP Connection/ SPP Disconnection)” for the connection by Serial Port Profile.
0
The transceiver is equipped with a communication port on the connection of the internal PC board in the transceiver.
Refer to the service manual for details.
19 CONFIGURATION FOR EACH FUNCTION
19.4 Available Functions for COM Port
Common FUNC (K, F)/Ver 2.20 421
CONTENTS INDEX
