328 8163A/B, 8164A/B, 8166A/B User’s Guide
11 Installation and Maintenance
Figure 203 How to Remove a Front-Loadable Module
1 Lift the catch at the bottom front of the module.
2 With the catch lifted, pull the module out of the instrument. If the
module does not slide out freely, check that you have lifted the catch
high enough.
How to Fit a Front-Loadable Module
Do not use the electrical or optical connectors to push the module into
the instrument, as this can cause damage to the connectors.
Make sure that the line power is switched off before you fit a module.
