Keysight EXG and MXG X-Series Signal Generators User’s Guide 295

Using Custom Digital Modulation for N5172B/82B with Option 431 and 653/655/656/657

Using Finite Impulse Response (FIR) Filters with Custom Modulation

3. Use the numeric keypad to type the first value (−0.000076) from Table 9-1. As you press the

numeric keys, the numbers are displayed in the active entry area. (If you make a mistake, you

can correct it using the backspace key.)

4. Continue entering the coefficient values from the table in step 1 until all 16 values have been

entered.

Table 9-1

Coefficient Value Coefficient Value

0 −0.000076 8 −0.035667

1 −0.001747 9 −0.116753

2 −0.005144 10 −0.157348

3 −0.004424 11 −0.088484

4 0.007745 12 0.123414

5 0.029610 13 0.442748

6 0.043940 14 0.767329

7 0.025852 15 0.972149
