Keysight EXG and MXG X-Series Signal Generators User’s Guide 321
Using Multitone and Two-Tone Waveforms for N5172B/82B with Option 430 and 653/655/656/657
Using Two–Tone Softkeys
3. On the spectrum analyzer, temporarily turn off waveform averaging to refresh your view more
quickly. You should now see a left–aligned two–tone waveform that is similar to the one shown
in Figure 10-5.
Figure 10-5
Whenever a change is made to a setting while the two–tone generator is
operating (Two Tone Off On set to On), you must apply the change by
pressing the Apply Settings softkey before the updated waveform will be
generated. When you apply a change, the baseband generator creates a
two–tone waveform using the new settings and replaces the existing
waveform in ARB memory.
Carrier
Frequency
Upper Tone
Aligned with
Intermodulation
Distortion
Two–Tone
Channels
Carrier
Frequency
For details on each key, use key help as described on page56.
