TOS3200 191
A List of Messages
Appx
Other subsystem
IEEE488.2 common commands
TRIG
[:SEQ[1]] | [:TEST]1
:SOUR char IMM | BUS IMM char Yes Sets the trigger source. R/W 1
:HREL
Releases the in-progress status of the
interval time.
W3
SCPI Command Setting
Default
Respon
se
Affec
ted
Description R/W *
Program header
Parameter Unit
SCPI Command Setting
Default
Respon
se
Affec
ted
Description R/W *
Program header
Parameter Unit
DISP
:CONT numeric 0 to 10 5 NR3 Sets the screen brightness. R/W 1
:SIZE
char NORM | ENL NORM char
Switches the test-in-progress
display.
R/W 3
:UXV
bool OFF NR1
Sets whether or not to display the
voltage in expanded numeric
display mode.
R/W 3
MEM
:RCL NR1 0 to 99 Recalls the panel memory. W 3
:SAV NR1 0 to 99 Saves to the panel memory. W 3
:TITLE
NR1 0 to 99 Sets the panel memory number.
R/W 3
string 12 characters Sets the memory name.
OUTP
:LINE[:STATe] bool OFF NR1 Yes Turns on/off the EUT power line. R/W
3
IEEE488.2
common
command
Parameter Description R/W
*CLS Clears all the event registers. W
*ESE NR1 Sets the event status enable register bits. R/W
*ESR Queries the event status register. R
*IDN Queries the identification string (manufacturer information). R
*OPC
Causes the device to generate the operation complete message in the event status
register when all pending selected device operations have been finished.
R/W
*OPT Queries the installed options. R
*RCL NR1 Recalls the contents saved to the memory. W
*RST
Performs a device reset. Configures the device to a known condition independent
from the usage history of the device.
W
*SAV NR1 Saves the present settings to the memory. W
*SRE NR1 Sets the service request enable register. R/W
*STB
Queries the contents of the status byte register and the master summary status
message.
R
*TRG Trigger command. W
*TST Executes a self-test. R
*WAI
Prevents the device from executing subsequent commands or queries until all
operations in standby are complete.
W
