Fig. 4-7 Connection example for TC measurement
Connect test lead A to a part of the
enclosure that is not connected to the
protective ground.
Connect test leads A and B to a part of the
enclosure that is not connected to the
protective ground.
Connect test leads A and B to a part not
connected to the protective ground and a
part connected to the protective ground.
Connection a
Connection b
Connection c
