MMC Smart Drive Hardware Manual - 230V 1/3 PHASE MMC SMART DRIVE
Table 5-26: F1/F2 Encoder to FSM Motor Cables
For Connection Diagram, see Table 5-27 on page 99
Length Non-Flex P/N Hi-Flex P/N
1 M (3.3 ft) M.1301.3927 N/A
3 M (9.8 ft) M.1301.4011 N/A
9 M (29.5 ft) M.1301.4012 N/A
15 M (49.2 ft) M.1301.4013 N/A
30 M (98.4 ft) M.1301.4014 N/A
