Table 5-28: F1/F2 Encoder to YSM Motor Cables
For Connection Diagram, see Table 5-29 on page 101
Length Non-Flex P/N Hi-Flex P/N
1 M (3.3 ft) M.1301.3983 N/A
2 M (6.6 ft) M.1302.7675 N/A
3 M (9.8 ft) M.1301.3984 N/A
9 M (29.5 ft) M.1301.3985 N/A
15 M (49.2 ft) M.1301.3986 N/A
30 M (98.4 ft) M.1301.3987 N/A
