MMC Smart Drive Hardware Manual - 230V 1/3 PHASE MMC SMART DRIVE
Table 5-20: F1/F2 Resolver to AKM/DDR Motor Cables
For Connection Diagram, see Table 5-21 on page 93
Length Non-Flex P/N Hi-Flex P/N
1 M (3.3 ft M.1302.8618 M.1302.8630
3 M (9.8 ft) M.1302.8439 M.1302.8450
6 M (19.7 ft) M.1302.8619 M.1302.8631
9 M (29.5 ft) M.1302.8620 M.1302.8632
15 M (49.2 ft) M.1302.8621 M.1302.8633
30 M (98.4 ft) M.1302.8622 M.1302.8634
