MMC Smart Drive Hardware Manual - 230V 1/3 PHASE MMC SMART DRIVE
Table 5-22: F1/F2 Encoder to AKM/DDR Motor Cables
For Connection Diagram, see Table 5-23 on page 95
Length Non-Flex P/N Hi-Flex P/N
1 M (3.3 ft) M.1302.8590 M.1302.8600
3 M (9.8 ft) M.1302.8447 M.1302.8435
6 M (19.7 ft) M.1302.8591 M.1302.8601
9 M (29.5 ft) M.1302.8542 M.1302.8602
15 M (49.2 ft) M.1302.8594 M.1302.8603
30 M (98.4 ft) M.1302.8595 M.1302.8604
