Konica Minolta C652 - Outside of the Main Body (Rear)

bizhub C652/C552 2-6
2.2 Main Body
2
2.2.2 Outside of the main body (rear)
The illustration above shows the main unit with an optional video interface kit, fax kit, and mount kit.
No. Name
1 Finisher connector
2Filter
3 Power cord
4Power switch for dehumidifying heater
5 Jack for connecting a telephone (TEL PORT2)
6 Telephone jack 2 (LINE PORT2)
1
2
13
10
11
12
9
8
34
7
5
6
