bizhub C652/C552 12-8
12.3 Options
12
Saddle stitcher SD-508
*
Not applicable to multi-function jobs (jobs with multiple functions combined).
Specification
Feeding function Center Staple and Fold, Half-Fold, Tri-Fold
(Belt conveyer feeding)
Paper type Center Staple: Plain paper (17 lb to 23-15/16 lb)
Half-Fold or Tri-Fold: Plain paper (17 lb to 23-15/16 lb)
Paper size Center Staple and Fold, Half-Fold: 12 e 18 w
*
to 8-1/2 e 11 w, A3w, B4w,
A4w, 8K w
Width: 8-1/4 to 12-3/8, length: 11 to 18-1/16
Tri-Fold: 8-1/2 e 11 w, A4w, 16K w
*
12 e 18 is 304.8 e 457.2 mm that is one-size larger than A3.
Maximum number of
sheets that can be center-
stapled
20 or 19 sheets + Thick (55-5/8 lb) 1 sheet
Maximum number of fold-
ed sheets
Half-Fold: 3 sheets
Tri-Fold: 3 sheets
Number of sheets that can
be loaded into the folding
output tray
Plain paper (21-1/4 lb)
*
When the length of paper is 13
or more
One sheet folded 50 sets
Two sheets stapled
and folded
20 sets
Three sheets stapled
and folded
16 sets
Four sheets stapled 12 sets
Five sheets stapled 8 sets
Six to 15 sheets sta-
pled
5 sets
16 to 20 sheets sta-
pled
5 sets
Tri-Fold -
When the length of paper is 13
or less
One sheet folded 10 sets
Two sheets stapled
and folded
10 sets
Three sheets stapled
and folded
10 sets
Four sheets stapled 5 sets
Five sheets stapled 5 sets
Six to 15 sheets sta-
pled
5 sets
16 to 20 sheets sta-
pled
4 sets
Tri-Fold 30 sets
Size Width 11-1/16e Depth 23-5/8e Height 20-7/8
Weight Approx. 41 lb, Approx. 7-1/2 lb (Output tray)
Consumables Staple MS-5C
For EH-554 (Product No. 500 manufactured by MAX) (5,000 staples includ-
ed) e 1 unit
Power supply Supply from finisher
