Konica Minolta C652 - Control Panel

bizhub C652/C552 2-9
2.2 Main Body
2
2.2.4 Control panel
7 Charger-cleaning tool
8 Imaging unit release lever
9 Toner cartridges
10 Original glass
11 Original scales
12 Jam removal dial
13 Original glass cleaner
No. Name
No. Name
1Touch pen
2Touch panel
3 Main power indicator
4 Sub power switch
5Function key
6 Data indicator
7Keypad
8 Brightness adjustment dial
1 2
3
5
4
8
7 6
