bizhub C652/C552 2-14
2.3 Option
2
* Press the output tray switch to move folded and center stapled paper to the end of the folding output tray.
4 Horizontal transport unit cover
5 Guide lever [FN7]
6 Guide lever [FN9]
7 Jam removal dial [FN6]
8 Jam removal dial [FN5]
9 Guide lever [FN3]
10 Guide lever [FN4]
11 Jam removal dial [FN8]
12 Guide lever [FN10]
13 Recessed pull
14 Jam removal dial [FN11]
15 Saddle stitcher
16 Output belt
17 Output tray switch
*
18 Folding output tray
19 Jam removal dial [FN3]
20 Guide lever [FN1]
21 Staple replacement door
22 Guide lever [FN13]
23 Guide lever [FN12]
24 Exit cover
