Kyocera Taskalfa Pro 15000c - Banner Tray <Banner Guide 10; Sheet Finisher <DF-9100>

To Next Page

To Previous Page

2-25

Machine Overview > Names of Optional Equipments

4,000-sheet Finisher <DF-9100>

Banner Tray <Banner Guide 10>

1 Output Cover

2 Tray A

3 Tray B

4 Front Cover 2

5 Front Cover 1 Lever

6 Front Cover 1

1 Paper clamp bar

2 Paper support

3 Paper Width Guide

4 Paper Width Guide Lock Lever
