Chapter 6 - page 13
Operator’s manual ASTRONAUT
M-HE.002.1003
Torque values:
• Check if all bolts and nuts are correctly secured.
• Tighten loose bolts / nuts with a torque listed below.
• Always apply Molykote P37 lubricant to the thread of the stainless steel bolts and nuts which
were disassembled. In this way, it will be much easier to disassemble them a second time.
6.2.4 Yearly maintenance
NOTE
• Always sort out any failures immediately.
Beside the inspection which is conducted according to the local requirements for earthing/grounding, it is strongly
recommended to have the earthing/grounding of the installation checked at least once a year by a authorized
installation technician.
Table 6.1 Torque values
M3 M4 M5 M6 M8 M10 M12 M16 M20
Nm 1,5 2,0 4,0 6,5 15 35 55 135 275
kgm 0,2 0,2 0,4 0,7 1,5 3,5 5,5 13,5 27,5
