Firmware ≤ 11.00 - DMS 8.0 EN - 10/2011 L 199
8400 StateLine C | Reference manual
Motor control (MCTRL)
Parameterisable additional functions
Short overview of the relevant parameters:
Distribution of the interpolation points
The saturation characteristic is defined by 17 interpolation points which are distributed
linearly on the x axis.
Interpolation point 17 represents 100 % of the maximum motor current in the process
(C02855
).
[5-17] Saturation characteristic: Distribution of the interpolation points
Note!
The saturation characteristic is not only used for the correction of the current
controller but also influences the current controller feedforward control
(C00079/1
).
Parameter Info Lenze setting
Value Unit
C02853/1...17 Lss saturation characteristic 100 %
C02855
Imax Lss saturation characteristic 3000.0 A
C02859
Activate Lss saturation charact. 0: Off
