8400 StateLine C | Reference manual
System bus "CAN on board"
Going online via system bus (CAN on board)
434 L Firmware ≤ 11.00 - DMS 8.0 EN - 10/2011
10.4 Going online via system bus (CAN on board)
The integrated system bus interface (CAN on board, X1 terminal) can also be used for the
communication between the »Engineer« and the controller, alternatively to the USB
diagnostic adapter.
Lenze offers the following communication accessories for connection to the PC:
10.5 Reinitialising the CANopen system bus interface
The C00002/26
= "1: On / start" device command reinitialises the CANopen system bus
interface of the controller ("Reset node"), which is required after e.g. changing the data
transfer rate, the node address or the identifiers, respectively.
Communication accessories PC interface
PC system bus adapter 2173
incl. connection cable and voltage supply adapter
• for DIN keyboard connection (EMF2173IB)
• for PS/2 keyboard connection (EMF2173IBV002)
• for PS/2 keyboard connection with electrical isolation (EMF2173IBV003)
Parallel interface
(LPT port)
PC system bus adapter 2177
incl. connection cable (EMF2177IB)
USB
(Universal Serial Bus)
Note!
• For detailed information about the PC system bus adapter, please see the
"CAN Communication Manual".
• Please observe the documentation for the PC system bus adapter!
• In the »Engineer«, go to the Device assignment offline devices dialog box and
select the "System bus CAN" entry from the Bus connection list field to
establish an online connection.
