8400 StateLine C | Reference manual
Working with the FB Editor
Reconfiguring the predefined interconnection
758 L Firmware ≤ 11.00 - DMS 8.0 EN - 10/2011
15.4.4.4 Deleting connections that are no longer required
How to delete connection lines:
1. Select connection lines to be deleted.
• Select a single connection line by directly clicking on the connection line with
the right mouse button.
• If you click further connection lines while pressing <Ctrl> they are added to an
already existing selection (multi-selection).
• All connection lines are highlighted in red.
2. Press <Del>.
How to delete port identifiers/flags:
1. Select the port identifiers to be deleted.
• Select a single port identifier by directly clicking on the port identifier with the
left mouse button.
• If you click further port identifiers while pressing <Ctrl> they are added to an
already existing selection (multi-selection).
• All selected port identifiers are highlighted by a light green header.
2. Press <Del>.
Related topics
Deleting objects that are no longer required
( 750)
