8400 StateLine C | Reference manual
System bus "CAN on board"
Possible settings via DIP switch
432 L Firmware ≤ 11.00 - DMS 8.0 EN - 10/2011
10.2.2 Setting the baud rate
The baud rate can be set via code C00351
or with the DIP switches a to d.
10.2.3 Setting the node address
The node address can be set via code C00350
or with the DIP switches 1 to 64.
The labelling on the housing corresponds to the values of the individual DIP switches
for determining the node address.
The valid address range depends on the number of SDO channels set in C00366
:
– 1 SDO (Lenze setting): 1 ... 127
–2 SDO: 1...63
Note!
• All DIP switches (a ... d, 1 ... 64) = OFF (Lenze setting):
– At switching on, the settings under code C00350
(node address) and
C00351
(baud rate) will become active.
• Preset baud rate: 500 kbps
DIP switch position Baud rate
d c b A
OFF ON OFF ON 20 kbps
OFF OFF ON ON 50 kbps
OFF OFF ON OFF 125 kbps
OFF OFF OFF ON 250 kbps
OFF OFF OFF OFF 500 kbps
OFF ON OFF OFF 1000 kbps*
* From version 11.00.00
Note!
• The addresses of the nodes must differ from each other.
• All DIP switches (a ... d, 1 ... 64) = OFF (Lenze setting):
– At switching on, the settings under code C00350
(node address) and
C00351
(baud rate) will become active.
