Firmware ≤ 11.00 - DMS 8.0 EN - 10/2011 L 863
8400 StateLine C | Reference manual
Function library
System blocks | LS_MotionControlKernel
Parameter
16.2.12 LS_MotionControlKernel
Interface to the basic drive functions implemented in Motion Control Kernel (MCK).
16.2.13 LS_MotorInterface
Interface to internal motor control.
Parameter Possible settings Info
C00727/1...8
0 1 Keypad digital values
• Execution of control commands
for keypad operation
• See the "Outputs" table for the
meaning of the individual
subcodes
C00728/1...3
-199.99 % 199.99 Analog values - keypad
• Specification of various setpoints
for keypad operation
• See the "Outputs" table for the
meaning of the individual
subcodes
For a detailed description see the main chapter "Basic drive functions":
Internal interfaces | System block "LS_MotionControlKernel"
( 353)
For a detailed description see the main chapterl "Motor control (MCTRL)":
Internal interfaces | system block "LS_MotorInterface"
( 245)
