8400 StateLine C | Reference manual
Introduction: Parameterising the controller
General notes on parameters
40 L Firmware ≤ 11.00 - DMS 8.0 EN - 10/2011
2.3.4 User menu for quick access to frequently used parameters
When a system is installed, parameters must be changed time and again until the system
runs satisfactorily. The user menu of a device contains a selection of frequently used
parameters to be able to access and change these parameters quickly.
Tip!
The user menu can be freely configured in C00517
.
In the »Engineer«, you can configure the user menu comfortably via the User menu
tab (see »Engineer« online help).
The password protection
serves to restrict the access to parameters of the user
menu. Then, all other parameters cannot be accessed without knowing the
password and are thus protected against unwanted changes.
Parameter Name Lenze setting
C00051 MCTRL: Actual speed value -
C00053 DC-bus voltage -
C00054 Motor current -
C00061 Heatsink temperature -
C00137 Device status -
C00166/3 Mess. - status det. error -
C00011
Appl.: Reference speed 1500 rpm
C00039/1
Fixed setpoint 1 40.00 %
C00039/2
Fixed setpoint 2 60.00 %
C00012
Acceleration time - main setpoint 2.000 s
C00013
Deceleration time - main setpoint 2.000 s
C00015
VFC: V/f base frequency 50 Hz
C00016
VFC: Vmin boost 1.60 %
C00022
Imax in motor mode depending on the device power
C00120
Setting of motor overload (I
2
xt) 100.00 %
C00087
Rated motor speed 1460 rpm
C00099 Firmware version -
C00200 Firmware product type -
C00105
Decel. time - quick stop 2.000 s
C00173
Mains voltage 0: "3ph 400V / 1ph 230V"
Highlighted in grey = display parameter
