8400 StateLine C | Reference manual
Technology applications
TA "Actuating drive speed"
302 L Firmware ≤ 11.00 - DMS 8.0 EN - 10/2011
7.2.3 Terminal assignment of the control modes
The following comparison provides information about which inputs/outputs of the application block LA_NCtrl are interconnected
to the digital and analog input/output terminals of the drive controller in the different control modes.
Control mode (C00007)
10: Terminals 0 12: Terminals 2 14: Terminals 11 16: Terminal 16 20: Keypad 21: PC 30: CAN 40: MCI
Digital input terminals
X4/RFR Controller enable / Reset of error message
bFailReset
X4/DI1 Fixed setpoint 1/3
bJogSpeed1
Change of direction of
rotation
bSetSpeedCcw
Fixed setpoint 1/3
bJogSpeed1
- - Quick stop
bSetQuickstop
X4/DI2 Fixed setpoint 2/3
bJogSpeed2
Activate manual DC-
injection braking (DCB)
bSetDCBrake
Fixed setpoint 2/3
bJogSpeed2
- - - -
X4/DI3 Activate manual DC-
injection braking (DCB)
bSetDCBrake
Quick stop
bSetQuickstop
Motor potentiometer:
Increase speed
bMPotUp
CW rotation quick stop
bRLQCw
- - - -
X4/DI4 Change of direction of rotation
bSetSpeedCcw
Motor potentiometer:
Decrease speed
bMPotDown
CCW rotation quick stop
bRLQCcw
- - - -
Analog input terminals
X3/A1U, A1I Main speed setpoint
nMainSetValue_a
10 V ≡ 100 % reference speed (C00011
)
- - Additional speed setpoint
nAuxSetValue_a
10 V ≡ 100 % reference speed (C00011
)
Digital output terminals
X4/DO1 Status "Drive is ready"
bDriveReady
X101/COM, NO Status "Error is pending"
bDriveFail
Analog output terminal
X3/O1U Actual speed value
nMotorSpeedAct_a
10 V ≡ 100 % reference speed (C00011
)
