Firmware ≤ 11.00 - DMS 8.0 EN - 10/2011 L 279
8400 StateLine C | Reference manual
I/O terminals
Analog terminals
6.2.2 Parameterising analog output
Click the button on the Terminal assignment tab to go to the parameterisation dialog
for the analog output:
Short overview of the parameters for the analog output:
Parameter Info Lenze setting
Value Unit
Analog output 1
C00434/1
O1U: Gain 100.00 %
C00435/1
O1U: Offset 0.00 %
C00439/1 O1U: Input value (from application) - %
Highlighted in grey = display parameter
