8400 StateLine C | Reference manual
Function library
System blocks | LS_DisFree_a
860 L Firmware ≤ 11.00 - DMS 8.0 EN - 10/2011
16.2.8.1 Display of internal process factors in application units
This function extension is available from version 06.00.00!
In addition to the display in percent in C00482/1...8
, for the first four analog signals
nDis1_a ... nDis4_a the configurable display parameters C00487/1...4
are provided. Via
these display parameters, internal process variables can be displayed, e.g. on the keypad,
with an individual scaling and an individual unit.
Configuration of the display parameters (C00487/1...4
):
[16-27] Formula for scaling the display
Example 1:
Input variable nDis1_a = 100 %
Offset 1 (C00484/1
) = 0 %
Display factor 1 (C00485/1
) = 123.45
Text 1 (C00486/1
) = "bottles"
Example 2:
Input variable nDis2_a = 40 %
Offset 2 (C00484/2
) = 35 %
Display factor 2 (C00485/2
) = 20
Text 2 (C00486/2
) = "kg"
Parameter Possible settings Info
C00484/1...4
-199.99 % 199.99 Offset 1 ... 4
• See formula [16-27]
.
• Lenze setting: 0.00 %
C00485/1...4
-65536.0000 65536.0000 Display factor 1 ... 4
• Scaling of the input variable for
the display.
• See formula [16-27]
.
• Lenze setting: 1.0000
C00486/1...4
String of digits Text 1 ... 4
• For each display value, an
individual unit (e.g. "bottles") can
be set.
