8400 StateLine C | Reference manual
Parameter reference
Table of attributes
714 L Firmware ≤ 11.00 - DMS 8.0 EN - 10/2011
C00352 CAN Slave/Master 24223 5E9F E 1 UNSIGNED_8 1 ;;
C00353
CAN IN/OUT COBID source 24222 5E9E A 3 UNSIGNED_8 1 ;;
C00354
COBID 24221 5E9D A 6 UNSIGNED_32 1 ;;
C00355
Active COBID 24220 5E9C A 6 UNSIGNED_16 1 ;
C00356
CAN time settings 24219 5E9B A 5 UNSIGNED_16 1 ;;
C00357
CAN monitoring times 24218 5E9A A 3 UNSIGNED_16 1 ;;
C00358
CANx_OUT data length 24217 5E99 A 3 UNSIGNED_8 1 ;;
C00359
CAN status 24216 5E98 E 1 UNSIGNED_8 1 ;
C00360
CAN telegram counter 24215 5E97 A 12 UNSIGNED_16 1 ;
C00364
CAN MessageError 24211 5E93 E 1 UNSIGNED_8 1 ;
C00366
Number of CAN SDO channels 24209 5E91 E 1 UNSIGNED_8 1 ;;
C00367
CAN Sync-Rx-Identifier 24208 5E90 E 1 UNSIGNED_16 1 ;;
C00368
CAN Sync-Tx-Identifier 24207 5E8F E 1 UNSIGNED_16 1 ;;
C00369
CAN Sync transmission cycle time 24206 5E8E E 1 UNSIGNED_16 1 ;;
C00370
SyncTxRxTimes 24205 5E8D A 2 INTEGER_16 1 ;
C00372
CAN_Tx_Rx_Error 24203 5E8B A 4 UNSIGNED_8 1 ;
C00381
CAN Heartbeat producer time 24194 5E82 E 1 UNSIGNED_16 1 ;;
C00385
CAN node addr. HeartBeat producer 24190 5E7E A 7 UNSIGNED_8 1 ;;
C00386
ConsumerTime HeartBeat producer 24189 5E7D A 7 UNSIGNED_16 1 ;;
C00400
LS_PulseGenerator 24175 5E6F A 3 UNSIGNED_16 1 ;;
C00401
CANxInOut: Inversion 24174 5E6E A 6 UNSIGNED_16 1 ;;
C00408
LP_CanIn mapping selection 24167 5E67 A 3 UNSIGNED_8 1 ;;
C00409
LP_CanIn mapping 24166 5E66 A 12 UNSIGNED_16 1 ;;
C00410
L_SignalMonitor_a: Signal sources 24165 5E65 A 4 UNSIGNED_16 1 ;;
C00411
L_SignalMonitor_b: Signal sources 24164 5E64 A 4 UNSIGNED_16 1 ;;
C00412
L_SignalMonitor_b: Inversion 24163 5E63 E 1 UNSIGNED_8 1 ;;
C00413
L_SignalMonitor_a: Offs./gain 24162 5E62 A 8 INTEGER_16 100 ;;
C00420
Encoder number of increments 24155 5E5B A 1 UNSIGNED_16 1 ;;
C00423
DOx: Delay times 24152 5E58 A 4 UNSIGNED_16 1000 ;;
C00425
Encoder scanning time 24150 5E56 A 1 UNSIGNED_8 1 ;;;
C00434
O1U: Gain 24141 5E4D A 1 INTEGER_16 100 ;;
C00435
O1U: Offset 24140 5E4C A 1 INTEGER_16 100 ;;
C00436
O1U: Voltage 24139 5E4B A 1 INTEGER_16 100 ;
C00439
O1U: Input value 24136 5E48 A 1 INTEGER_16 100 ;
C00440
LS_AnalogIn1: PT1 time constant 24135 5E47 A 1 UNSIGNED_16 1 ;;
C00441
Decoupling AnalogOut 24134 5E46 E 1 UNSIGNED_16 1 ;;
C00442
AOut1: Disconnect value 24133 5E45 A 1 INTEGER_16 100 ;;
C00443
DIx: Level 24132 5E44 A 2 UNSIGNED_16 1 ;
C00444
DOx: Level 24131 5E43 A 2 UNSIGNED_16 1 ;
C00445
FreqInxx_nOut_v 24130 5E42 A 1 INTEGER_16 1 ;
C00446
FreqInxx_nOut_a 24129 5E41 A 1 INTEGER_16 100 ;
C00447
DigOut decoupling 24128 5E40 E 1 UNSIGNED_16 1 ;;
C00448
DigOut decoupling value 24127 5E3F E 1 UNSIGNED_16 1 ;;
C00449
FreqInxx_dnOut_p 24126 5E3E A 1 INTEGER_32 1 ;
C00461
Remote: Acceleration/deceleration
time
24114 5E32 A 1 UNSIGNED_32 1000 ;;
C00462
Remote: Control 24113 5E31 A 2 UNSIGNED_16 1 ;;
C00463
Remote: MCK control 24112 5E30 A 1 UNSIGNED_32 1 ;;
C00464
Remote: Monitoring timeout 24111 5E2F A 1 UNSIGNED_16 1 ;;
C00465
Keypad: Time-out welcome screen 24110 5E2E E 1 INTEGER_32 1 ;;
C00466
Keypad: Default parameter 24109 5E2D E 1 INTEGER_32 1 ;;
Code Name Index Data Access
dec hex DS DA DT Factor R W CINH
