8400 StateLine C | Reference manual
Parameter reference
Table of attributes
716 L Firmware ≤ 11.00 - DMS 8.0 EN - 10/2011
C00606 Resp. to motor overload (I²xt) 23969 5DA1 E 1 UNSIGNED_8 1 ;;
C00607
Resp. to max. freq. feedb. DIG12/67 23968 5DA0 E 1 UNSIGNED_8 1 ;;
C00608
Resp. to maximum torque 23967 5D9F E 1 UNSIGNED_8 1 ;;
C00609
Resp. to maximum current 23966 5D9E E 1 UNSIGNED_8 1 ;;
C00620
System connection list: 16-bit 23955 5D93 A 104 UNSIGNED_16 1 ;;
C00621
System connection list: Bool 23954 5D92 A 175 UNSIGNED_16 1 ;;
C00622
System connection list: Angle 23953 5D91 A 24 UNSIGNED_16 1 ;;
C00632
L_NSet_1: Max. skip freq. 23943 5D87 A 3 INTEGER_16 100 ;;
C00633
L_NSet_1: Min. skip freq. 23942 5D86 A 3 INTEGER_16 100 ;;
C00634
L_NSet_1: wState 23941 5D85 E 1 UNSIGNED_16 1 ;
C00635
L_NSet_1: nMaxLimit 23940 5D84 E 1 INTEGER_16 100 ;;
C00636
L_NSet_1: nMinLimit 23939 5D83 E 1 INTEGER_16 100 ;;
C00637
L_NSet_1: Output blocking zones 23938 5D82 E 1 INTEGER_16 100 ;
C00638
L_NSet_1: Output ramp rounding 23937 5D81 E 1 INTEGER_16 100 ;
C00639
L_NSet_1: Output add.value 23936 5D80 E 1 INTEGER_16 100 ;
C00640
L_NSet_1: nNOut_a 23935 5D7F E 1 INTEGER_16 100 ;
C00643
Resp. to PLI monitoring 23932 5D7C A 1 UNSIGNED_8 1 ;;
C00670
L_OffsetGainP_1: Gain 23905 5D61 E 1 INTEGER_32 10000 ;;
C00671
L_OffsetGainP_2: Gain 23904 5D60 E 1 INTEGER_32 10000 ;;
C00672
L_OffsetGainP_3: Gain 23903 5D5F E 1 INTEGER_32 10000 ;;
C00680
L_Compare_1: Fct. 23895 5D57 E 1 UNSIGNED_8 1 ;;
C00681
L_Compare_1: Hysteresis 23894 5D56 E 1 INTEGER_16 100 ;;
C00682
L_Compare_1: Window 23893 5D55 E 1 INTEGER_16 100 ;;
C00685
L_Compare_2: Fct. 23890 5D52 E 1 UNSIGNED_8 1 ;;
C00686
L_Compare_2: Hysteresis 23889 5D51 E 1 INTEGER_16 100 ;;
C00687
L_Compare_2: Window 23888 5D50 E 1 INTEGER_16 100 ;;
C00690
L_Compare_3: Fct. 23885 5D4D E 1 UNSIGNED_8 1 ;;
C00691
L_Compare_3: Hysteresis 23884 5D4C E 1 INTEGER_16 100 ;;
C00692
L_Compare_3: Window 23883 5D4B E 1 INTEGER_16 100 ;;
C00696
L_OffsetGainP_1: Offset 23879 5D47 E 1 INTEGER_16 100 ;;
C00697
L_OffsetGainP_2: Offset 23878 5D46 E 1 INTEGER_16 100 ;;
C00698
L_OffsetGainP_3: Offset 23877 5D45 E 1 INTEGER_16 100 ;;
C00699
L_MulDiv_1: Parameter 23876 5D44 A 2 INTEGER_16 1 ;;
C00700
LA_NCtrl: Analog connection list 23875 5D43 A 29 UNSIGNED_16 1 ;;
C00701
LA_NCtrl: Digital connection list 23874 5D42 A 48 UNSIGNED_16 1 ;;
C00720
L_DigitalDelay_1: Delay 23855 5D2F A 2 UNSIGNED_32 1000 ;;
C00725
Current switching frequency 23850 5D2A E 1 UNSIGNED_8 1 ;
C00727
LS_Keypad digital values 23848 5D28 A 8 UNSIGNED_8 1 ;;
C00728
Analog values - keypad 23847 5D27 A 3 INTEGER_16 100 ;;
C00729
Remote: Setpoint selection 23846 5D26 A 2 INTEGER_16 100 ;;
C00760
LA_SwitchPos: Analog connection list 23815 5D07 A 25 UNSIGNED_16 1 ;;
C00761
LA_SwitchPos: Digital connection list 23814 5D06 A 47 UNSIGNED_16 1 ;;
C00800
L_MPot_1: Upper limit 23775 5CDF E 1 INTEGER_16 100 ;;
C00801
L_MPot_1: Lower limit 23774 5CDE E 1 INTEGER_16 100 ;;
C00802
L_MPot_1: Acceleration time 23773 5CDD E 1 UNSIGNED_16 10 ;;
C00803
L_MPot_1: Deceleration time 23772 5CDC E 1 UNSIGNED_16 10 ;;
C00804
L_MPot_1: Inactive fct. 23771 5CDB E 1 UNSIGNED_8 1 ;;
C00805
L_MPot_1: Init fct. 23770 5CDA E 1 UNSIGNED_8 1 ;;
C00806
L_MPot_1: Use 23769 5CD9 E 1 UNSIGNED_8 1 ;;
C00820
L_DigitalLogic_1: Function 23755 5CCB E 1 UNSIGNED_8 1 ;;
C00821
L_DigitalLogic_1: Truth table 23754 5CCA A 8 UNSIGNED_8 1 ;;
Code Name Index Data Access
dec hex DS DA DT Factor R W CINH
