8400 StateLine C | Reference manual
Function library
Function blocks | L_MPot_1
810 L Firmware ≤ 11.00 - DMS 8.0 EN - 10/2011
Outputs
Parameter
Identifier
Data type
Value/meaning
nOut_a
INT
Output signal
Parameter Possible settings Info
C00800
-199.99 % 199.99 Upper limit
• Lenze setting: 100.00 %
C00801
-199.99 % 199.99 Lower limit
• Lenze setting: -100.00 %
C00802
0.1 s 6000.0 Acceleration time
• Lenze setting: 10.0 s
C00803
0.1 s 6000.0 Deceleration time
• Lenze setting: 10.0 s
C00804
Inactive function
• Selection of response when
deactivating the motor
potentiometer via the input
bInAct.
• Lenze setting: 0
0No further action; nOut_a retains its
value.
1 The motor potentiometer returns to
0 % within the deceleration time T
if
2 The motor potentiometer runs to
the lower limit value (C00801
)
within the deceleration time T
if
3 The motor potentiometer output
immediately changes to 0 %
Important for the emergency stop
function
4 The motor potentiometer output
immediately changes to the lower
limit value (C00801
)
5 The motor potentiometer runs to
the upper limit value (C00800
)
within the acceleration time T
ir
C00805 Init function
• Selection of response when
switching on the device.
• Lenze setting: 0
0 The output value being output
during mains power-off is saved
non-volatilely in the internal
memory of the controller. It will be
reloaded during mains power-on.
1 The lower limit value (C00801
) is
loaded during mains power-on.
2 An output value = 0 % is loaded
during mains power-on.
C00806
Use of the motor potentiometer
• When switching to 1: YES, the
value applied to nIn_a is
automatically transferred to the
motor potentiometer.
• Lenze setting: 0
0No
1Yes
