The
operang range of an asynchronous motor consists of the voltage range
①
and the eld
weakening range. The eld weakening range is divided into two ranges:
•
In the rst range
②
, the power can be kept constant without the motor stalling.
•
The second eld weakening range
③
is characterised by the fact that the maximum
permissible stator current is decreased to prevent the motor from stalling .
Speed/torque curve of the asynchronous motor with two eld weakening ranges
0
0.2
0.3
0.4
0.5
0.6
0.7
0.8
0.9
1.0
0.1
1.1 1.2 1.3 1.4 1.5 1.6 1.7 1.8 1.9
2.0
0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1.0
2.1 2.2 2.3 2.4 2.5 2.6 2.7 2.8 2.9 3.0 3.1 3.2 3.3 3.4
n
1
M = M
2 *
n ²/n²
2
M
2
n
2
M = M
max
M = M
max *
n
1
/n
The override point (n
2
, M
2
) c
an be inuenced with 0x2B0C (P319.00).
0x2B0C (P319.00) > 0 Hz:
•
The maximum current characterisc is shied to higher eld frequencies by the frequency
entered.
•
The maximum permissible current and the maximum torque increase in the eld
weakening range.
•
The risk of motor stalling increases.
0x2B0C (P319.00) < 0 Hz:
•
The maximum current characterisc is shied to lower eld frequencies by the frequency
entered.
•
The maximum permissible current and the maximum torque are reduced in the eld
weakening range.
•
The risk of motor stalling is reduced.
Parameter
Address Name / seng range / [default seng] Informaon
0x2B0C
(P319.00)
Override eld weakening
(Field w
eak thold)
-599.0 ... [0.0] ... 599.0 Hz
Oset of the override point for eld weakening.
Conguring the motor control
V
/f characterisc control for asynchronous motor (VFC open loop)
Opmising the stalling behaviour
