LEXIUM MHDA1004 - External Fuse Specifications Table

114
Electrical Specifications - Power, continued
External Fuse
Specifications
Table
The following table provides 17D external fuse specifications..
Continued on next page
Input Type Model Number Fuse
Schneider Electric
Fusetron - 230V
Reference
Fusetron - 480V
Reference
Line
MHDA1004•00 6 A,
aM
FRN/FRN-R-6 FRS/FRS-R-6
MHDA1008•00
MHDA1017•00 10 A,
aM
FRN/FRN-R-10 FRS/FRS-R-10
MHDA1028•00 16 A,
aM
FRN/FRN-R-15 FRS/FRS-R-15
MHDA1056•00 25 A,
aM
FRN/FRN-R-25 FRS/FRS-R-25
Ballast externe MHDA1004•00 4 A, fast acting*
DF2-CN04
MHDA1008•00
MHDA1017•00 6 A, fast acting*
DF2-CN06
MHDA1028•00
MHDA1056•00
*Two fuses in series, >= 500 V, dimensions : 10 x 38.
