LEXIUM MHDA1004 - External Regen Resistor Assembly

40
External Regen Resistor Mounting and Physical Dimensions, continued
External regen
resistor
assembly
CAUTION !
Surface temperature can
exceed 200°C. Observe
the requested free space.
Do not mount on
combustible material !
100
60
3030
Air flow
