Electrical Specifications - Power, continued
Internal Power
Dissipation
Specifications
Table
The following table provides 17D internal power dissipation at maximum
continuous output power. This information may be useful to size the thermal
capability of the mounting cabinet.
Note: These power dissipations are measured at maximum continuous power and
should be considered worst case. Often in sizing servo systems, factors such as
profile duty cycle may reduce these numbers. These values do not include power
dissipated in the Regen resistor. This is application-specific and must be calculated
separately.
Quiescent dissipation when output stage is disabled is 15 W
Model Number Power
MHDA1004
•00
30 W
MHDA1008
•00
40 W
MHDA1017
•00
60 W
MHDA1028
•00
90 W
MHDA1056
•00
200 W
