LEXIUM MHDA1004 - External Regen Resistor Assembly Dimensions

39
External Regen Resistor Mounting and Physical Dimensions
External Regen
Resistor
Assembly
Dimensions
The following diagram shows the dimensions for all three external Regen resistor
assemblies.
F
E
D
A
C
B
E
G
+Rb
ext
-Rb
ext
PE
Regen Resistor
Assembly
Part Number
A B C D E F G Weight
mm mm mm mm mm mm mm Kg
342 352 410 64 45 4,8 x 8 77 1,5
413 428 485 93 64 6,5 x 12 120 4,0
AM0RFE001V025
AM0RFE001V050
513 528 585 186 150 120 8,0
AM0RFE 001V150
Power
W
250
600
1500
6,5 x 12
R
Ω
33
33
33
