LEXIUM MHDA1004 - Wiring the BPH Motor Power Connector (Excluded BPH055)

154
Wiring the Motor Power Connector (Drive end), continued
Wiring the BPH
Motor Power
Connector
(excluded
BPH055)
The following diagram shows the 13 steps required to wire a motor power
connector (excluded BPH055).
Wiring the Motor Power Connector (Drive end)
2
1
3
4
56
7
8
9
10
11
12
13
70 mm
Green/Yellow
1 2 3
White Black
10 mm
(1) U (2) V (3) W PE (Green/Yellow) (White) Br+ (Black) Br-
U V W PE Br+ Br-
6 5 4 3 2 1
1 2 3 Green/Yellow White Black
Power Cable
Connection
Pinout
Lexium BPH
5 1
6
24
55 mm
15 mm
30 mm
45 mm
For U, V and W)
Green/Yellow
6 5 4 2 1
Bottom view
*number of wires are printed every 10 cm.
Black White
