16
The 17D Series Servo Drive Family
Introducing the
17D Drive Family
Each member of the Lexium 17D series family is comprised of a three-phase
brushless servo amplifier, power supply and high-performance digital controller all
housed in a single enclosure.
Drives
Available
The 17D drives are available in five models which are correlated to different output
current levels as identified in the following table.
Implementing
the Drives
The Lexium 17D servo drives are intended for incorporation into electrical
equipment or machinery and can only be commissioned as integral components of
those types of devices.
Applicable Servo
Motor Types
The Lexium 17D servo drives are intended to drive BPH and SER series brushless
servo motors.
Continued on next page
Output Current Intermittent (Peak) 17D Drive
4A
MHDA1004
•00
8A
MHDA1008
•00
17A
MHDA1017
•00
28A
MHDA1028
•00
56A
MHDA1056
•00
Note:
A00 means that restart lock -AS- is included.
N00 standard version
