LEXIUM MHDA1004 - Wiring a 17 D drive to Quantum 140 MSx motion modules

129
External 24 Vdc supply
External 24Vdc
supply
A reminder of the a 24 V consumption for the Lexium MHDA servodrives with BHP
motors is given below.
Lexium servodrive MHDA1004/
1008
/ 00
MHDA1017
/ 00 MHDA1028 / 00 MHDA1056 / 00
Associated BPH motor 075• 095• 095• 115• 095• 115• 142• 142• 190•
Current without brake (A) 0.75 0.75 0.75 0.75 0.75 0.75 0.75 1.2 1.2
Current with brake (A) 1.25 1.45 1.45 1.55 1.45 1.55 1.75 2.2 2.7
Description Output voltage Rating Parallel connection Ref. Weight
VA
Kg
Module
∼ 100...240 V
50/60 - 400 Hz
and 125 Vdc
24 Vdc
SELV
1.1
Yes TSX SUP 1011
(1) (2)
0.720
Module
∼ 100...120 V
and
∼ 200...240V,
50/60 - 400 Hz
24 Vdc
SELV
2.2 Yes TSX SUP 1021
(1) (2)
1.090
5YesTSX SUP 1051
(1) (2)
1.120
Unit
∼ 100...120V and
∼ 200...240V,
50/60 - 400 Hz
24 Vdc
SELV
10 Yes TSX SUP 1101
(1)
2.100
(1) Product supplied as standard with a bilingual reference guide: French and English.
(2) Mounted in Premium TSX RKY 6/8/12/6E/8E/12E racks (any slot except the slot for TSX PSY••0M
power supply modules), on AM1-DE200/DP200 rails or on AM1-PA mounting plate.
