147
D
Cable Connection Wiring
Diagrams
At a Glance
What’s in this
Appendix
This appendix provides procedures and diagrams that show you how to wire
certain cable connectors that are used with the Lexium 17D drive.
This appendix presents the following topics.
Topic Page
Wiring a Sub-D connector with shielding (drive side) 148
Wiring the feedback connector of the motors 150
Wiring the Motor Power Connector (drive end) 153
Serial communications interface connector (X6) RS 232 157
