Electrical Specifications - Signal, continued
Encoder Input
Specifications
Table
The following table provides 17D encoder input specifications
Emulated
Encoder Output
(Incremental
Format)
Specifications
Table
The following table provides 17D emulated encoder output (in incremental format)
specifications.
Continued on next page
ENCODER INPUT
Internal power supply Voltage 9V ± 5%
Current (maximum) 200 mA
Input Signal Sin-Cos encoder
(cyclic absolute)
Absolute
accuracy
15 bits (39
arc-seconds
or 0.01
°)
Resolution 20 bits (1.2
arc-seconds
or 0.0003
°)
Sin-Cos encoder
(multi-turn absolute)
Turn counter 12 bits
Absolute
accuracy
within one
turn
15 bits (39
arc-seconds
or 0.01
°)
Resolution
within one
turn
20 bits (1.2
arc-seconds
or 0.0003
°)
EMULATED ENCODER OUTPUT (INCREMENTAL FORMAT)
Channels A, B, and Marker
Type Differential, RS-485 compliant
Resolution with:
Resolver feedback
Sin-Cos Encoder feedback
Resolution:
16...1024
16...4096 and
8192...524288 (2
n
)
